Sunflow Pumps

Sunflowpumps SFX

Flanged mounted gear pumps are modified version of SF series pumps with wider capacity range and facility for foot or flange mounting . Useful for pumping and transfer of all viscous liquids , oil , and Petroleum Products.

FEATURE

- Concept: helical gear pumps

- Brand: sunflow

- Pressure : 0-10 kg/cm2

- Temperature : 50 c- 250c

- Speed: 1440 RPM

- Sturdy construction

- Perfect Design

- Low-leakage path

- Low noise, high efficiency , Reliable by Low Cost

- Higher Aesthetic value

APPLICTION

- SUNFLOW Rotary gear pumps are useful for handling viscous liquids, Tranfer the liquid one place to another place , all kind of Oils , viscous chemical and Following liquid can be handle with them

- All kind of mineral oils, All kind of vegetable oils, coal bar, Bituman asphates , printing inks and Dyes, All kind of fish and animals oils Glycerine and glycol Fuel oil Diesel oil, Furnance oil viscous chemical

TECHANICAL SPECIFICATION

		CAPACITY AT 1440 RPM
PUMP MODEL	SECTION & DELIVERY SIZE	LPM	US GPM	M³/hr
SFX-025	1/4" X 1/4"	2.5	0.65	0.15
		5	1.30	0.30
SFX-050	1/2" X 1/2"	10	2.65	0.6
		15	4	0.90
SFX-075	3/4" X 3/4"	20	5.30	1.2
		25	6.60	1.5
SFX-100	1" X 1"	35	9.25	2.1
		50	13.20	3.0
SFX-125	1¼ " X 1¼"	60	15.85	3.6
		75	19.80	4.5
SFX-150	1½" X 1½"	100	26.40	6.0
		125	33	7.5
SFX-200	2" X 2"	150	39.65	9.0
		200	52.80	12.0
SFX-250	2½" X 2½"	300	79.25	18.0
		350	92.50	21.0

Sunflowpumps SF

Useful For pumping and transfer of all viscous liquids , oil , and petroleum products.

Dhyey Engineering Works offers Helical Gear pumps SF series. It is available in cast iron grade with single helical alloy steel gears and hardned and ground shafts. It has study design and construction to give long and trouble free life and performance utra bronze bush material ensure smoother running than conventional phosphorous bronze. It is available size ½” to 3” capacity range of 20 to 500 LPM and can operate upto max pressure of 10 kg/cm2 .

FEATURE

- Compact Design.

- Economical Prices.

- Wide capacity range.

- Foot and Flange mounting options.

APPLICTION

- Centralize lubrication system.

- Pumping and heating system.

- Oil fitration and cleaning system.

- Transformer oil purification system.

- Machine tools industries.

TECHANICAL SPECIFICATION

		CAPACITY AT 1440 RPM
PUMP MODEL	SECTION & DELIVERY SIZE	LPM	US GPM	M³/hr
SF-025	1/4" X 1/4"	5	1.30	0.30
SF-050	1/2" X 1/2"	20	5.30	1.20
SF-075	3/4" X 3/4"	30	7.90	1.80
SF-100	1" X 1"	50	13.20	3.00
SF-125	1¼"X 1¼"	75	19.80	4.50
SF-150	1½" X 1½"	110	29.00	6.60
SF-200	2" X 2"	225	59.40	13.50
SF-250	2½" X 2½"	350	92.50	21.00
SF-300	3" X 3"	500	132.00	30.00

Sunflowpumps SFSS

Sunflow Rotary Gear Pumps with SS 316 Construction The Pumps Have SS 316 Gears and Shafts That Nitrides to Give Longer Life with Trouble-Free Performance The Shaft Supported On Self Lubricating Type Teflon Coated DU Bushes and Sealing Is Done With Teflon Based Z Pack Sealant Which Gives Zero Leakage and Easy To Maintain These Pumps Are Available In Flange and Foot Mounting Type This Can Operate Up To Max. Pressure 10Kg|cm2 and Capacity Up To 25 to 300 LPM and Size Available 1/4 TO 2½ Hygienic Viscous Liquid Transfer One Place to another Place.

Use This Compact & Efficient SS Pumps Find Different Application for Handling Food Product Likes Ghee Butter Fruit Pulp Vegetable Souse Kanji etc. They are also used in Pharmaceutical application for Handing Sugar Solution, Glycerin Glycol etc. corrosives Viscous Chemicals Application can also be met With this pump most effectively

MATERIAL OF CONSTRUCTION

- Pump Body : CF8M-SS316 Dom Nut : AISI SS316

- Front Cover : CF8M-SS316 Sealing: Z" Pack TEFLON

- Back Cover: CF8M-SS316 Packing : Teflon Sheet

- Gland Cover : CF8M-SS316 Key Coupling : SS304

- R.H & L.H Gear AISI SS 316

- Rotor |Stator Shaft AISI SS 316

- Bush Bearing: Teflon Coated DU

- Moating Bracket : C1 Gr 20 IS 210

TECHANICAL SPECIFICATION

		CAPACITY AT 1440 RPM
PUMP MODEL	SECTION & DELIVERY SIZE	LPM	US GPM	M³/hr
SFSS-025	1/8" X 1/8"	5.0	1.30	0.30
SFSS-025	1/4" X 1/4"	8.3	2.2	0.50
SFSS-040	3/8" X 3/8"	16.7	4.4	1.00
SFSS-050	1/2" X 1/2"	25.0	6.6	1.50
SFSS-075	3/4" X 3/4"	33.3	8.8	2.00
SFSS-100	1" X 1"	50.0	13.2	3.00
SFSS-125	1¼" X 1¼"	100.0	26.4	6.00
SFSS-150	1½" X 1½"	125.0	33.0	7.5
SFSS-200	2" X 2"	150	39.6	9.00
SFSS-200	2" X 2"	200	52.8	12.00
SFSS-250	2½" X 2½"	250	66.0	15.00
SFSS-250	2½" X 2½"	300	79.25	18.00

Sunflowpumps SFMP

Dhyey enginneering works is well recognized and accepted name in the list of lubrication gear pump manufacturer they after a comprehensive range of pumps which are meant for accomplishing various purpose. All the products are manufactured by following the intementional standard including and strict policy their highly recommended lubrication gear pump is made for lubricating all types of machines.

FEATURE

- Brand : Sunflow

- Capacity : 0.5 LPM to 30 LPM(LPM)

- 7 different modes are available which can operate at

- 1440 RPM who pressure up to 10 kg/cm2

- size 1/4". 1/2". 3/4"1"

- concept : Internal Gear pump

TECHANICAL SPECIFICATION

PUMP MODEL	CAPACITY IN LPM AT 1440 RPM	SECTION & DELIVERY SIZE	Motor Rating Required [HP]
SFMP-0.5	0.5 LPM	1/8" X 1/8"	0.25
SFMP-1	1 LPM	1/4" X 1/4"	0.25
SFMP-3	3 LPM	1/4" X 1/4"	0.25
SFMP-6	6 LPM	1/4" X 1/4"	0.50
SFMP-10	10 LPM	3/8" X 3/8"	0.50
SFMP-16	16 LPM	1/2" X 1/2"	1
SFMP-25	25 LPM	1/2" X 1/2"	1.5
SFMP-40	40 LPM	1" X 1"	1.5

Sunflowpumps FIG

Riding on unfathomable volumes of industrial expertise we are offering an excellent range of fuel injection gear pump. offfered pump is fabricated by our industry experts in order to meet the varied application requirement. It is made available in both anticlockwise and clockwise direction our skilled professional take care that this pump meet the universally accepted guidelines of quality and is of excellent strength.

SALIENT FEATURE

- Capacity :- 1000/4500 LPM at max Head of 30kg/cm2 pressure.

- Positive Displacement internal Gear pump at constant pressure for handling only non-corrosive and non-abrassive liquids.

- High precision pumps ensuring desired output.

- Compact easy installation in any position .

- Noise free and smooth running.

TECHANICAL SPECIFICATION

			MOTOR HP
PUMP MODEL	SECTION & DELIVERY SIZE	CAP. IN LPM AT 1440 RPM	3 Kg/cm²	30 Kg/cm²
FIG-S505	3/8" X 3/8"	50	0.25	1.00
FIG-S508	3/8" X 3/8"	80	0.25	1.00
FIG-A15	1/2" X 1/2"	150	0.25	1.50
FIG-A30	1/2" X 1/2"	300	0.25	1.50
FIG-A45	1/2" X 1/2"	450	0.25	2.00
FIG-A60	1/2" X 1/2"	600	0.25	2.00
FIG-B100	3/4" X 3/4"	1000	0.75	3.00
FIG-B150	3/4" X 3/4"	1500	0.75	3.00
FIG-B200	3/4" X 3/4"	2000	0.75	5.00
FIG-B250	3/4" X 3/4"	2500	0.25	5.00
FIG-C300	1" X 1"	3000	1.50	7.50
FIG-C450	1" X 1"	4500	1.50	10.00
FIG-C600	1" X 1"	6000	1.50	15.00

Sunflowpumps SFMS

Dhyey Engineering works made sun flow brand gear pump model SFMS which is heavy duty Gear pumps. The foot mounting type positive displacement rotary twin gear pump. This Pump having all stainless steel with investment cast. These pump having a double helical Refined ss.316 gear shaft that are nitrated to give longer life. This pump self-lubricated pump.

The Teflon coated dry running DU bush bearing supported on bronze wearing plate. These Pump provide with add-on type pressure relief valve.

FEATURE

- Range : 1/2" to 6" size

- Brand : Sun flow

- Pressure : 10 kg/cm2

- Capacity : 13 LPM to 1335 LPM

- Temperature : up to 200’c

- Viscosity : 1,00,000 SSU

MATERIAL CONSTRUCTION

- Pump body : CF8M [SS316]

- Front Cover : CF8M [SS316]

- Back Cover : CF8M [SS316]

- Gland Cover : CF8M [SS316]

- Rotor and Stator Shaft: AISI [SS316]

- Bushes : Tafton coated W

- Key : SS304

- Sealing : GFO Pack / Mach Seal R.V assembly AISI [SS316]

TECHANICAL SPECIFICATION

		CAPACITY AT 1440 RPM
PUMP MODEL	SECTION & DELIVERY SIZE	LPM	US GPM	M³/hr
SFMS-050-S	1/2" X 1/2"	13	3.3	0.75
SFMS-050-M	1/2" X 1/2"	16.6	4.4	1.00
SFMS-100-S	1" X 1"	3	7.92	1.80
SFMS-100-M	1" X 1"	37.5	9.9	2.25
SFMS-150-S	1½" X 1½"	60	15.8	3.60
SFMS-150-M	1½" X 1½"	75	19.8	4.50
SFMS-200-S	2" X 2"	100	26.4	6.00
SFMS-200-M	2" X 2"	150	33.0	7.50
SFMS-250-S	2½" X 2½"	150	40.00	9.00
SFMS-250-S	2½" X 2½"	200	52.9	12.00
SFMS-300-S	3" X 3"	250	66.0	15.00
SFMS-300-M	3" X 3"	333	88.0	20.00
SFMS-400-S	4" X 4"	415	111.0	25.00
SFMS-400-M	4" X 4"	500	132.9	30.00
SFMS-500-S	5" X 5"	600	158.0	36.00
SFMS-500-M	5" X 5"	750	197.5	45.00
SFMS-600-S	6" X 6"	1000	263.0	60.00
SFMS-600-M	6" X 6"	1335	351.0	80.00

APPLICATION

- Foam pressurising application for firefighting.

- High Pressure Coolant Transfer

- Handling thinner liquid at moderate mearing.

- Heavy liquid transfer one place to another place like Magna Tar, Molasses, Soap Stock, Varmus

Sunflowpumps SFRN

Heavy duty gear pumps (positive displacement twins gear pump) type SFRN/ SFRB/ SFRX series pump are useful for steel plant, power plant, pumping station Petroleum industry and refineries, cool tas paint. Veg oil, crude oil, molasses, Bitumen, Lube oil, Heavy oil.

Heavy duty gear pumps available size from ½ “ to 8” NB (Flanged to ASA 150 Classes)

FEATURE

- Capacity : 0.5 to 200 m3 /hr

- Pressure : 12 kg / cm2

- Viscosity : 100000 CST

- Temperature : 100 C to 200 C

- Heavy duty design pump for continuous

- Herringbone rotor design eliminate side thru

- Modified tooth profile enhances tooth life.

- Floating gear design ensures uniform load distribution.

- Optional Steam Jacket.

APPLICATION

- Steel Plant

- Power Plant

- Refineries

- Pumping Station

- Tanker Loading and Un-Loading

- Molasses All Acidy Liquids Bitumen Luke Oil Heavy Oil

- Veg. Oil Mineral Oil Crude Oil

TECHANICAL SPECIFICATION

	CAPACITY AT 1440 RPM
PUMP MODEL	LPM	US GPM	M³/hr
1/2"	8.30	2.20	0.50
50	16.60	4.40	1.00
S-M-L	25.00	6.60	1.50
1"	33.30	8.80	2.00
100	50	13.20	3.00
S-M-L	60.00	15.84	3.60
1⅟2"	83.30	22.00	5.00
150	100.00	26.40	6.00
S-M-L	125.00	33.30	7.50
2"	150.00	39.00	9.00
200	166.00	44.00	10.00
S-M-L	200	52.80	12.00
2⅟2"	250.00	66.00	15.00
250	299.33	79.20	18.00
S-M-L	333.30	88.00	20.00
3"	415.00	105.00	25.00
300	449.82	118.00	27.00
S-M-L	500	132.00	30.00
4"	599.00	158.00	36.00
400	666.66	176.00	40.00
S-M-L	833.80	220.00	50.00
5"	1000.00	264.00	60.00
500	1250.00	330.00	75.00
S-M-L	1499.00	396.00	90.00
6"	1660.00	440.00	100.00
600	1832.00	884.00	110.00
600	1832.00	884.00	110.00
S-M-L	2083.00	550.00	125.00
